ACTIVE DEFENSE BARRIER | Hydraulic Model Height 35 cm Width from 2 to 5 meters

ACTIVE DEFENSE BARRIER - WITHSTANDS RAMMING VEHICLES

Retractable impact-resistant obstacle combining ease of installation, simplicity of use, robustness and reduced maintenance.

Safety features:

- No 220 v voltage in the obstacle pit

- Positive safety: locked in the raised position on power failure, or negative safety: lowers on power failure

- Inductive loop pass-through safety (option)

- Manual lifting pump (no voltage required)

Certification: Computer simulation

Ref VLRB 35 cm = 3 T at 15 Km/h

Ref PLRB 53 cm = 5 T at 25 Km/h

Ref PLRB 80 cm = 10 T at 30 Km/h

Construction:

- Retractable obstacles are made of steel

- Width from 2 to 5 m

- Heights 35 cm

- Lifting time: 3 to 6 seconds depending on length

- Raised by hydraulic cylinders

- Hydraulic pump in a remote enclosure allowing the electronic board (PLC) and the motor-pump unit to be grouped together

- Power supply 240 V single-phase or 400 three-phase

- RAL paint of choice

- Anti-vandal lock on control cabinet

Options:

- Vehicle safety loops

- Pedestrian sensors

- Manual pump

- Signal lights (green / red)

- Lights integrated into the obstacle

- Access control (badges - keypad codes, remote controls, etc.)

- Door forced-entry contact

- Armoured cabinet
