Note
Mounting dimensions Form A for plate thickness 6 mm.
Mounting dimensions Form B for plate thickness 6 to 16 mm.
A gap of more than 0.1 mm appears between the plates if the retaining force is exceeded.
Attention
The specified pullout forces only apply in conjunction with locating bush 03192-02.
Accessory
Locating bush 03192-02.
Characteristic(s)
Material
Housing and push button stainless steel.
Ball, spring and snap ring stainless steel.
O-ring FKM.
Version
Housing bright.
Push button bright.
Ball tempered.
