Description
BENEFITS:
- Robust and lightweight box-section structure
- Base made of standardised elements held in stock
- Drawbar with ball coupling with triple positive safety (robustness, reliability) preventing accidental uncoupling
- Diamond-positioned wheels allowing easy rotation and positioning at the workstation (manoeuvrability)
- Reduced breakaway and rolling forces due to its design (depending on the type of wheels selected)
- Noise reduction (75 dbA instead of 115dbA for conventional load rollers) on flat, smooth floors
- Improved behaviour of the base unit (path tracking with short drawbar, emergency braking), allowing use in narrower aisles
- Towing speed up to 15 km/h
- Towing up to 15 bases or 7 tonnes
- Interchangeable drawbar, wheel and gully types
- Resistant surface treatment
- Reliable product with reduced maintenance cost
- Base able to carry dynamic shelving structures, racks, etc.
- Equipment guaranteed for 1 year(s) (see general warranty conditions)
- CE marking and compliance with European Directives
STANDARD TECHNICAL SPECIFICATIONS:
- Designed for indoor use on clean, flat and smooth floors
- Double-skin platform, 60 mm thickness, sheet steel 2 mm thickness
- Internal platform dimensions: 830 x 630 mm
- Floor-to-platform-top height: 300 mm
- 4 gullies in the corners measuring 100 x 100 x 100 mm
- 4 anti-tip stabilisers
- 4 wheels (2 fixed and 2 swivel) diamond-positioned. Diameter 200 mm, aluminium rim, black rubber tyre
- Long ergo-drawbar pack (800 mm): articulated drawbar with 2 handles on front support with coupling box, and ball with safety cam at rear
- Tare weight: 110 kg
- Maximum permissible load: 500 kg - Finish by glycerophthalic paint (RAL grey 9006)
- Robust and lightweight box-section structure
- Base made of standardised elements held in stock
- Drawbar with ball coupling with triple positive safety (robustness, reliability) preventing accidental uncoupling
- Diamond-positioned wheels allowing easy rotation and positioning at the workstation (manoeuvrability)
- Reduced breakaway and rolling forces due to its design (depending on the type of wheels selected)
- Noise reduction (75 dbA instead of 115dbA for conventional load rollers) on flat, smooth floors
- Improved behaviour of the base unit (path tracking with short drawbar, emergency braking), allowing use in narrower aisles
- Towing speed up to 15 km/h
- Towing up to 15 bases or 7 tonnes
- Interchangeable drawbar, wheel and gully types
- Resistant surface treatment
- Reliable product with reduced maintenance cost
- Base able to carry dynamic shelving structures, racks, etc.
- Equipment guaranteed for 1 year(s) (see general warranty conditions)
- CE marking and compliance with European Directives
STANDARD TECHNICAL SPECIFICATIONS:
- Designed for indoor use on clean, flat and smooth floors
- Double-skin platform, 60 mm thickness, sheet steel 2 mm thickness
- Internal platform dimensions: 830 x 630 mm
- Floor-to-platform-top height: 300 mm
- 4 gullies in the corners measuring 100 x 100 x 100 mm
- 4 anti-tip stabilisers
- 4 wheels (2 fixed and 2 swivel) diamond-positioned. Diameter 200 mm, aluminium rim, black rubber tyre
- Long ergo-drawbar pack (800 mm): articulated drawbar with 2 handles on front support with coupling box, and ball with safety cam at rear
- Tare weight: 110 kg
- Maximum permissible load: 500 kg - Finish by glycerophthalic paint (RAL grey 9006)
Technical specifications
| Category | Packing, Handling, Logistics |
|---|---|
| Subcategory | Handling, Lifting |
