fixating for co-ordinate measuring machines, module

Clamping component set for CMM's for quick and flexible clamping of small parts. This consists of basic, add-on and clamping elements. The set can be used to precisely position and securely clamp a wide variety of workpieces such as plastic, punched and turned parts. Clamping of parts, a frequent problem in measurement tasks, is thus largely solved.

Dimension D1 refers to the basic quick-action clamp 33227-05, which differs in the sets.

Advantages

Individual assembly of single parts for measuring in coordinate measuring machines.

Scope of delivery
1x Basic quick-action clamp 33227-05.
1x Rotatable quick-action clamp with angle element 34007-1.
1x Precision vice 33225-5003511.
1x Precision 3-jaw chuck with adapter 34011-065.
1x Small-parts clamp 34012-110005.
1x Support set for precision 3-jaw chuck.
