These high-quality ball guide pins have been specially developed to ensure maximum precision, stability and durability.
With an integrated collar, the ball guide pins provide an optimal basis for mounting ball guide units. The collar enables precise and secure alignment of the unit, resulting in smooth movement and reliable guidance of tools and dies.
The 3+1 principle ensures the correct assembly of the two die halves. 3 guide elements with large diameters and 1 guide element with a smaller diameter are incorporated.
Characteristic(s)Application area(s)
Material
Ball guide pins low carbon steel 1.7139.
Version
case-hardened.
Steel ball guide pins are the perfect choice for precise guiding tasks in tool and die making as well as in demanding manufacturing processes
