The principle of the vacuum lifting device allows to distribute the weight of the load on each of the suction cups and thus to eliminate the handling effort. The operator has an ergonomic remote handlebar for a flexible and secure manual handling. He is no longer in direct contact with the load.
The lifting beam can be equipped with silicone suction cups, suction cups with foam seal or suction foam plates.
The INGENITEC suction foam plate is a suction gripping system that allows different loads to be lifted and handled, individually or in layers, with a single gripper, without any adjustment or tool change. Extremely easy to handle, it is particularly suitable for handling fragile and delicate loads, and meets the high hygiene standards required in certain sectors of activity.
The INGENITEC vacuum lifting device can be positioned under a telescopic column, a parallelogram jib, an electric hoist or a lifting tube. INGENITEC offers you a global handling solution, depending on your working environment and the application required.
Application example:
Main features:
- Gripper: silicone suction cups, foam gasket suction cups or vacuum foam plates
- Number of suction cups determined according to the handling needs
- Fixed suction cups or adjustable position on the spreader
- Horizontal and/or vertical pick-up and set-down
- Pneumatic or electric lifting device - Possibility of autonomous operation on battery
Areas of application :
- Palletizing/de-palletizing operations
- Handling of wooden plates, sheet metal plates, marble plates, cardboard, glass, drums, pallets, reels, rolls... individually or in layers
- Logistics, wood industries, automated industries, food industries...
