The indexing plungers with bushes are a perfect combination for rapid positioning and fixing. The precise design of both the indexing plungers and the bush guarantees high repeating accuracy when assembling two elements.
Technical Information see assembly and installation instructions.
Drawing reference:
Form A: standard
Form B: lockable
Characteristic(s)
Material:
Steel.
Grip ball thermoplastic.
Version:
Hardened and ground.
Grip ball black grey.
